Special offers PS-1045

80mm thick insulated roof panels - A-grade - RAL7016 anthracite grey

Price / m²
EUR 42.00
  • Available quantity: 84
  • Length: 6 m - 7.5 m
  • Width: 1 m
 Your Enquiry for Special Offer
Roof
Roof
84 pcs.
PU 12

Special offer details

6m & 7.5m lengths, 1m wide

Price ex-UK

Rigid PUR (Polyurethane) Insulation, PIR (Polyisocyanurate) available on request

Colour RAL7016 anthracite grey outer RAL9010 white inner

Lengths 6m & 7.5m, width 1m

Price valid if you order 1 pack minimum (7 panels per pack)

Can also produce new panels to your dimensions & colour (closest match)

Flashings & screws also available

Delivery UK & Ireland

Package information

Quantity Length Width Area (sqm) Colour (both sides)
63 6 m 1 m 378 m² External colour: RAL 7016 (anthracite), Internal colour: RAL 9010 (pure white)
21 7.5 m 1 m 157.5 m² External colour: RAL 7016 (anthracite), Internal colour: RAL 9010 (pure white)

panel sell North America

U-Value

PIR

Core thickness
[mm]
U-Value
[W/m² K]
30 0.71
40 0.54
50 0.44
60 0.37
80 0.28
100 0.22
120 0.19
150 0.15
180 0.12
200 0.11
220 0.1
240 0.09

Rockwool

Core thickness
[mm]
U-Value
[W/m² K]
50 0.69
60 0.59
80 0.45
100 0.37
120 0.31
140 0.27
160 0.24
180 0.21
200 0.19

PIR

Core thickness
[mm]
U-Value
[W/m² K]
30 0.64
40 0.49
60 0.34
80 0.26
100 0.21
120 0.18
150 0.15

Rockwool

Core thickness
[mm]
U-Value
[W/m² K]
50 0.76
60 0.63
80 0.47
100 0.38
120 0.32
150 0.25
180 0.21
200 0.19

PIR

Core thickness
[mm]
U-Value
[W/m² K]
60 0.37
80 0.26
100 0.21
120 0.18
150 0.14
180 0.12
200 0.11
Weight

PIR

Core thickness
[mm]
Weight
[kg]
40 7.9 - 9.6
60 8.7 - 10.8
80 9.5 - 11.6
100 10.3 - 12.4
120 11.1 - 13.2

Rockwool

Core thickness
[mm]
Weight
[kg]
50 14.6
60 15.6
80 17.6
100 19.6
120 21.6
140 23.6
160 25.6
180 27.6
200 29.6

All information without guarantee for completeness and correctness. Information includes variations in sheet thickness, insulation materials and type of fastening. Technical changes reserved.

PIR

Core thickness
[mm]
Weight
[kg]
30 11.5
40 11.9
50 -
60 12.7
80 13.4
100 14.2
120 14.9

Rockwool

Core thickness
[mm]
Weight
[kg]
30 -
40 -
50 13.9
60 14.9
80 16.9
100 18.9
120 20.9

All information without guarantee for completeness and correctness. Information includes variations in sheet thickness, insulation materials and type of fastening. Technical changes reserved.

PIR

Core thickness
[mm]
Weight
[kg]
80 11.4 - 13.1
100 12.2 - 13.9
120 13 - 14.7
150 14.2 - 15.9
180 15.4 - 17.1
200 16.2 - 17.9

All information without guarantee for completeness and correctness. Information includes variations in sheet thickness, insulation materials and type of fastening. Technical changes reserved.

Transport
