665m² in stock! Colour: RAL 7016 anthracite grey | various lengths
Thickness: 80mm
Colour: RAL 7016
Foam: PIR
Width: 1000mm
Secret fixings
The panels can be used as:
The price applies to purchases of over 250m²!
Delivery UK & Ireland wide.
Price excludes VAT and delivery.
ZSCH
Quantity | Length | Width | Area (sqm) | Colour (both sides) |
---|---|---|---|---|
3 | 3.5 m | 1 m | 10.5 m² | RAL 7016 |
2 | 3.85 m | 1 m | 7.7 m² | RAL 7016 |
22 | 5.86 m | 1 m | 128.92 m² | RAL 7016 |
22 | 6.41 m | 1 m | 141.02 m² | RAL 7016 |
44 | 7 m | 1 m | 308 m² | RAL 7016 |
8 | 8.75 m | 1 m | 70 m² | RAL 7016 |
panel sell North America
Core thickness [mm] | U-Value [W/m² K] |
---|---|
30 | 0.71 |
40 | 0.54 |
50 | 0.44 |
60 | 0.37 |
80 | 0.28 |
100 | 0.22 |
120 | 0.19 |
150 | 0.15 |
180 | 0.12 |
200 | 0.11 |
220 | 0.1 |
240 | 0.09 |
Core thickness [mm] | U-Value [W/m² K] |
---|---|
50 | 0.69 |
60 | 0.59 |
80 | 0.45 |
100 | 0.37 |
120 | 0.31 |
140 | 0.27 |
160 | 0.24 |
180 | 0.21 |
200 | 0.19 |
Core thickness [mm] | U-Value [W/m² K] |
---|---|
30 | 0.64 |
40 | 0.49 |
60 | 0.34 |
80 | 0.26 |
100 | 0.21 |
120 | 0.18 |
150 | 0.15 |
Core thickness [mm] | U-Value [W/m² K] |
---|---|
50 | 0.76 |
60 | 0.63 |
80 | 0.47 |
100 | 0.38 |
120 | 0.32 |
150 | 0.25 |
180 | 0.21 |
200 | 0.19 |
Core thickness [mm] | U-Value [W/m² K] |
---|---|
60 | 0.37 |
80 | 0.26 |
100 | 0.21 |
120 | 0.18 |
150 | 0.14 |
180 | 0.12 |
200 | 0.11 |
Core thickness [mm] | Weight [kg] |
---|---|
40 | 7.9 - 9.6 |
60 | 8.7 - 10.8 |
80 | 9.5 - 11.6 |
100 | 10.3 - 12.4 |
120 | 11.1 - 13.2 |
Core thickness [mm] | Weight [kg] |
---|---|
50 | 14.6 |
60 | 15.6 |
80 | 17.6 |
100 | 19.6 |
120 | 21.6 |
140 | 23.6 |
160 | 25.6 |
180 | 27.6 |
200 | 29.6 |
All information without guarantee for completeness and correctness. Information includes variations in sheet thickness, insulation materials and type of fastening. Technical changes reserved.
Core thickness [mm] | Weight [kg] |
---|---|
30 | 11.5 |
40 | 11.9 |
50 | - |
60 | 12.7 |
80 | 13.4 |
100 | 14.2 |
120 | 14.9 |
Core thickness [mm] | Weight [kg] |
---|---|
30 | - |
40 | - |
50 | 13.9 |
60 | 14.9 |
80 | 16.9 |
100 | 18.9 |
120 | 20.9 |
All information without guarantee for completeness and correctness. Information includes variations in sheet thickness, insulation materials and type of fastening. Technical changes reserved.
Core thickness [mm] | Weight [kg] |
---|---|
80 | 11.4 - 13.1 |
100 | 12.2 - 13.9 |
120 | 13 - 14.7 |
150 | 14.2 - 15.9 |
180 | 15.4 - 17.1 |
200 | 16.2 - 17.9 |
All information without guarantee for completeness and correctness. Information includes variations in sheet thickness, insulation materials and type of fastening. Technical changes reserved.
